Electrical Epoxy Resin Potting Compound for Insulation and Transformers

Name: Electrical Epoxy Resin Potting Compound for Insulation and Transformers
Brand: wenyou
Price: 1 USD

Quality Electrical Epoxy Resin Potting Compound for Insulation and Transformers for sale

Place of Origin : Shanghai, China

Brand Name : wenyou

Model Number : 9278

MOQ : 20

CAS No. : 1675-54-3

Molecular Formula : C21H24O4

EINECS No. : 216-823-5

Viscosity at 25℃ : 7500-12000 mPa.s

Density at 25℃ : 1.16-1.20 g/cm3

Flash point : about 135℃

Tensile strength : 65-85N/mm2

Flexural strength : 100-140N/mm2

Compressive strength : 140-180N/mm2

Impact strength : 9-16kJ/m2

Curing shrinkage : 0.8-1.0%

Thermal conductivity : 0.8-0.9W/mk

Thermal decomposition : ＞320℃

Surface resistivity : 1014Ω

Volume resistivity : 1015Ω.cm

Contact Now

Product Description

Bi-component Epoxy resin system/Liquid can be used to processes of Conventional casting process under vacuum. Excellent splitting resistance& heat shock resistance Excellent technical&mechanical properties. Property
Medium&high voltage insulation switch parts,such as: Insulators,10kv\35jv cyrrebt&voltage transformers and dry-type transformers etc. Applications

Formulation

Epoxy resin	LE-9287	100pbw
Hardener	LH-9287	100pbw
Filling	Silica flour (X10)	280-350pbw
Color paste	LC-series	3pbw

Application

Electrical Epoxy Resin Potting Compound for Insulation and Transformers

Our company products be used for medium&high voltage insulation .

Our company products be used for electrical insulators .

Our company products be used for transformers.

Packing & Delivery

Fully automated packaging.

Put up the products to ensure products safety.

Our company products are loading up waiting to be transported to port.

Product Paramenters

Title goes here.

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

Title goes here.

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

Properties	Unit	Value	Unit	Value
Appearance	Visual	Transparent viscous liquid	Visual	Light yellow- yellowish liquid
Viscosity at 25℃	mPa.s	7500-12000	mPa.s	300-600
Density at 25℃	g/cm3	1.16-1.20	g/cm3	1.17-1.24
Vapour Pressure at 25℃	Pa	﹤0.01	Pa	about 0.5
Flash point	℃	about 135	℃	about 140

Mechanical and physical properties

Properties	Value	Properties	Value
Tg（DSC）	75-95℃	Thermal conductivity	0.8-0.9W / mk
Tensile strength	65-85N/mm2	Thermal decomposition	＞320℃
Flexural strength	100-140N/ mm2	Water absorption (23℃×10days)	0.10-0.20 % by wt.
Compressive strength	140-180N/ mm2	Water absorption (100℃×60 mins)	0.08-0.15 % by wt.
Impact strength	9-16kJ/ m2	Surface resistivity	1014Ω
Curing shrinkage	0.8-1.0%	Volume resistivity	1015Ω.cm
Flammability（4mm）	HB Class	Dielectric strength	30 kV / mm
Flammability（12mm）	HB Class	Loss factor	0.02

Producing Process

Title goes here.

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

Title goes here.

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

Title goes here.

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

Applications

Title goes here.

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

Title goes here.

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

Title goes here.

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

Casting Process

Company profiles

Our company

Shanghai Wenyou Industry Co., Ltd. is a professional epoxy resin company in
Fengxian,Shanghai, China, specializing in the manufacturing, R&D, and sales of epoxy resin, curing agents, and related products.
Our wide range of products includes epoxy resin, flame retardant resin, curing agents, outdoor modifiers, toughening agents, epoxy
paste, demoulding agents, and fillers. Our high-quality products are used in high voltage electrical insulation applications and
are exported globally. We are committed to providing stable products and excellent service to the global electricity industry.
